EVGA - 220-GT-0850-Y1 SuperNOVA 850 GT 850W 80 Plus Gold Fully Modular Power Supply

EVGA 850W GT 80+ Gold Certified Power Supply (P/N: 220-GT-0850-Y1)

Key Features:

• Maximum Power Output: 850W
• 80+ Gold Certified Efficiency: 90% (115VAC) > 92% (230VAC) efficiency under typical loads
• Fully Modular Design: Simplifies cable management and improves airflow
• Compact Form Factor: Ideal for space-constrained builds
• Advanced Protections: Includes OVP, UVP, OCP, OPP, SCP, and Dual OTP for maximum safety
• Premium Components: 100% Japanese capacitors for superior reliability
• Quiet Cooling: Features a 135mm Fluid Dynamic Bearing fan and EVGA ECO mode for silent operation and long lifespan

Product Overview: The EVGA 850W GT Power Supply offers high efficiency, compact design, and robust performance, making it a perfect choice for gaming rigs or high-performance workstations. With 80+ Gold certification, it delivers up to 90% efficiency, reducing energy waste and ensuring stable power for your system. The fully modular design minimizes clutter, making installation and cable management easy while improving overall airflow.

Equipped with advanced protection features, including Over Voltage Protection (OVP), Under Voltage Protection (UVP), and more, this power supply ensures maximum safety for your components. It also includes Haswell support and is designed for long-term use with a MTBF of 100,000 hours.

Specifications:

Technical Information:

• Specification Compliance: ATX12V > EPS12V
• Efficiency: 90% (115VAC) > 92% (230VAC)
• Fans: 1 x 135mm Fluid Dynamic Bearing Fan for ultra-quiet cooling
• Modular: Yes, fully modular for easy cable management
• Energy Efficiency: 80 PLUS Gold Certified
• Power Description:
• Input Voltage: 120V AC > 230V AC
• Input Frequency Range: 50/60Hz
• Input Current: 10A - 5A
• Number of +12V Rails: 1
• Output Voltages:
  +3.3V @ 20A
  +5V @ 20A
  +12V @ 70.8A
  +5VSB @ 3A
  -12V @ 0.3A
• Total Power Output: 850W
• Physical Characteristics:
• Form Factor: Compact design
• Dimensions: 5.91 x 5.91 x 3.39 inches (W x D x H)
• Weight: 6 lbs (Approx.)
• Connectors:
• Main Connector: 20+4 Pin
• PCI-Express Connectors: 6 x 6+2 Pin
• SATA Power Connectors: 9
• Certifications & Approvals:
• TUV, CB, CE, FCC, RCM, cTUVus, BSMI, CCC, WEEE, RoHS
• MTBF (Mean Time Between Failures): 100,000 hours
